1993 XR200

Send any relevant info on the '93 XR200 to:  webmaster@justxr.com

1993 XR200 Bike Specifications:

Model Name:  XR200R2 2002 Model
Engine Type:  195cc air-cooled single-cylinder four-stroke
Bore x Stroke:  65.5mm x 57.8mm
Compression Ratio:  10.0:1
Carburettor(s):  24mm piston-valve
Ignition:  Solid-state CD
Transmission:  Six-speed
Final Drive:  #520 O-ring-sealed chain; 13T/47T

Wheel Base (mm):  1360mm
Seat Height (mm):  850mm
Ground Clearance (mm):  277mm
Fuel Capacity (litres):  9.1, 1.5 reserve

Front Tyre:  80/100-21
Rear Tyre:  100/100-17

Front Suspension:  36mm air-adjustable leading-axle Kayaba fork; 208mm travel
Rear Suspension:  Pro-Link Kayaba single shock with spring preload adjustability; 211mm travel

Front Brakes:  Drum

Rear Brakes:  Drum

Dry Weight (kg):  105

Other Info:

Engine & Drivetrain
• 195cc Air cooled 4 stroke single.
• 24mm carburetor.
• Quiet, USDA-qualified muffler/spark arrester.
• Primary kickstarting with automatic decompression system for easy starting in any gear.
• Lightweight aluminum crankcase.
• Maintenance-free solid-state CD ignition.
• Smooth-shifting, versatile six-speed transmission.
• Heavy-duty clutch offers smooth, progressive engagement.

Chassis/Suspension
• Lightweight semi-double-cradle high-tensile steel frame.
• 36mm leading-axle Kayaba front fork offers 8.2 inches of suspension travel.
• Fork boots keep dirt and moisture away from fork seals.
• Heavy-duty Kayaba rear shock.
• Pro-Link(r) rear suspension rides on needle bearings for smooth action and durability.
• Box-section steel swingarm with snail-type chain adjusters and drop-in axle holders for easy maintenance.
• Powerful, lightweight drum brakes.
• Strong, lightweight rims with straight-pull spokes.
• Heavy-duty O-ring-sealed chain for durability and reduced maintenance.
• Motocross-style seat is low, comfortable and allows maximum rider movement.
• 17-inch rear wheel contributes to a low seat height.
• Large, 2.4-gallon plastic fuel tank and thrifty four-stroke engine for long range.

Additional Features
• Easily detachable number plate.
• Tubular steel engine guard.
• Folding shift lever and brake pedal tips.
• Reusable foam air filter for reduced maintenance costs.
• Front and rear steel sprockets for durability.
• High-quality handlebar, comfortable grips and dogleg levers with brush guards.
• Cleated, folding, self-cleaning footpegs and brake pedal for secure footing.
